    1600mm PVC PE Adhesive Tape Cutting Making Machine Single Knife


    Features:


    1. Single knife and double shafts for high cutting effciency.
    2. Driven by sevo moto, cutting width can be set up freely, high precision.
    3. PLC programmable control, operating with touch screen and easy maintenance.
    4. Servo or hydraulic knife feeding, auto spraying for knife lubrication, neat cutting edge.
    5. Cutting with circular knife, main shaft stepless speed adjustable by frequency conerting, suiable for different kinds of material.
    6. Manual adjustment or auto adjustment for circular knife angle.
    7. Equipped with circular knife cooling system.


    Technical parameters:


    ModelC12-13C12-16
    Effective Width (mm)13001600
    Min. Cutting Width (mm)33
    Paper Tube ID (mm)Ø25~76Ø76
    Max. Cutting Dia. (mm)Ø150Ø150
    Cutting Speed (pc/min)3~103~10
    Air Pressure (Kg/cm²)88
    Total Power (KW)~7~7
    Dimension (L×W×H)(mm)3000X1300X15003300X1300X1500

    Application:

    Suitable for cutting of double-side tape, kraft paper tape, masking tape,foam tape,PET tape, PVC,PE, and cloth tape etc.

    1600mm PVC PE Adhesive Tape Cutting Making Machine Single Knife


    Company Information:


    1600mm PVC PE Adhesive Tape Cutting Making Machine Single Knife

    FAQ:

    1. Are you a factory?
    Yes, our company was established in 1998. It is the only comprehensive manufacturing enterprise in China produce both tape and
    tape machine.


    2. Can I get some tape samples for testing before placing order?
    Yes,we can provide you some free samples for your reference.


    3. How long is the delivery time for your tape?
    The first order is 15 days after deposit,then other orders are about 7-10 days after deposit.


    4. How could I get the quotation?
    Tape: Please let me know the specification(thickness,width,length),quantity,application and other requirements according to your
    needs so that we can provide an accurate quotation.

    Machine: please provide the type of machine required and other special requirements.


    5. Do you control the items quality?

    Each machine strictly tested one by one before shipping.


    6. How long is the delivery time for your machine?
    After deposit is about 30 days.


    7. What is quality guarantee policy?
    12 months guarantee for all goods from our company, but we do not accept any broken by man.


    8. When we receive the box, find any items missing or defective, how should we do?

    Please contact us ASAP, we will check and give you best solution soon.
