Automatic Plastic PP PE Woven Sack Flat Film Extrusion Machine

    Buy cheap Automatic Plastic PP PE Woven Sack Flat Film Extrusion Machine from wholesalers

    Buy cheap Automatic Plastic PP PE Woven Sack Flat Film Extrusion Machine from wholesalers
    • Buy cheap Automatic Plastic PP PE Woven Sack Flat Film Extrusion Machine from wholesalers
    • Buy cheap Automatic Plastic PP PE Woven Sack Flat Film Extrusion Machine from wholesalers

    Automatic Plastic PP PE Woven Sack Flat Film Extrusion Machine

    Ask Lasest Price
    Brand Name : unitedwin
    Model Number : UW
    Price :
    Payment Terms : T/T, L/C
    Supply Ability : 3 sets/month
    Delivery Time : 3 month
    Certification : CE&ISO
    • Product Details
    • Company Profile

    Automatic Plastic PP PE Woven Sack Flat Film Extrusion Machine

    Automatic Produce PP Woven Bag Plastic Tape Extrusion production line


    Features:

    1. Intelligent control system
    Contoled through the touch screen, for data storage, fault alarm function,easy operation
    2. Precision die heads
    The simulative extrusion test and CNC one time machine-shaping can guarantee the high quality of wires.
    3. High-speed winder
    With the constant tension winder converter speed control, the tension is uniform and the wire roll is smooth and flat.The speed is up to 450m/min.
    4. Multi-stations mixing and batching system (Optional)
    Automatic mixing and batching system is very precise, mixing evenly.The formula can be saved.

    Specifications:


    ItemSJPL-Z90×33-SM900SJPL-Z110×33-SM1100SJPL-Z120×33-SM1300SJPL-Z130×33-SM1500
    Max.Extrusion280kg/h320kg/h420kg/h500kg/h
    Screw Dia.Φ90mmΦ110mmΦ120mmΦ130mm
    scew RPM.20-100r/min20-100r/min20-100r/min20-100r/min
    T Die Head Lip length900mm1100mm1300mm1500mm
    SJJ Winder speed280m/min280m/min280m/min280m/min
    SHW Winder speed400m/min400m/min400m/min400m/min
    Tex.Range60-200tex60-200tex60-200tex60-200tex
    Winder No.S280340410480
    Power320KW350KW400KW450KW
    Size40000×3500×260042000×3500×260045000×3500×260048000×3500×2600
    Weight30T35T40T48T

    Application:


    Automatic Plastic PP PE Woven Sack Flat Film Extrusion Machine


    FAQ:

    1. Are you trading company or manufacturer?
    We are manufacturer, and also provide the business solution to all the friends.


    2. Do you have quality certificate?
    Yes we have CE, SGS etc.


    3. What's the delivery time?
    Around 20~30days, however, based on order.


    4. What is your overseas service?
    We will provide high quality overseas service ,our technical staff will be able to provide you with technical support, for you personally to overseas assembly and test equipment.


    5. what's payment terms ,trade terms you accept ?
    Usually we appreciate T/T 30% deposit , then 70% balance is paid before shipment , we usually offer fob ningbo price. but we alsoaccept other way like L/C , wetern union ,and do CFR&CIF etc.


    6. Can you be responsible for transport?

    Yes, please tell us the destination port or address. we have rich experience in transport.


    7. What's your packing?

    Large parts wrapped in several turns of films, small parts boxed in a wooden crate, each

    packaged is numbered and packed to easy loading/unloading and installation.
