    SBY-650X4 Four Shuttle Circular Loom Machine for Mesh Bag Onion bag

    Ask Lasest Price
    Brand Name : United Win
    Model Number : SBY-650X4
    Price : USD
    Supply Ability : 3 sets/ month
    Delivery Time : 3 months
    • Product Details
    • Company Profile

    SBY-650X4 Four Shuttle Circular Loom Machine for Mesh Bag Onion bag

    SBY-650X4 Four Shuttle Circular Loom Machine for Mesh Bag


    Description:


    UW series circular lloom, which adopts the SCM (Single Chip Microcomputer), carry out centralized control to the system; the parameter is set up and changed on HMI (Human Machine Interface). Main motor and take-up motor are respectively driven by dual inverters. The system can change and update the data in time, reaching high accuracy and move ahead simultaneously. The function of accurate weft cloth compensate, can carrying on by weft density adjustment in time, improving fabric's quality and the qualification rate. Mechanical malfunction can be displayed in sub-area and recorded in detail. Users may conveniently process the production management and control the system in real time on the HMI.


    Specifications:


    ItemSBY-650×4SBY-850X6HSBY-1350×6SBY-2200×6SBY-2250×10
    Number of shuttles(pcs)466610
    Folding width of cloth150-650mm300~850mm900-1350mm1500~2200mm1750~2250mm
    Number of warp576 pcs720pcs1200pcs2880pcs2880pcs
    weft density8-16(pcs/inch)
    Max. speed180r/min180-230r/min110r/min80r/min70r/min
    Power of main motor2.2 KW3kw5.5 KW7.5kw11kw
    Specification of Bobbin(ID×L)Ф28-38×230mm/218mm
    Max.weft Bobbin diameterФ 100Ф 115Ф 90
    Overall dimension(L×W×H)8500×2500×290010500×2800×292010850×3000×350016480×3600×4580mm16480×3600×4580mm
    Weight (about)2000kg2500kg4200kg8000kg9000kg

    Application:

    SBY-650X4 Four Shuttle Circular Loom Machine for Mesh Bag Onion bagSBY-650X4 Four Shuttle Circular Loom Machine for Mesh Bag Onion bag


    FAQ:

    1. How long will your engineer reach our factory?

    Within one week after everything ready (machine arrival your factory, non-woven material, power source, air compressor etc. Prepared)


    2. How many days will you finish installing?

    We will finish installation and training within 15 days.


    3. What should we charge for your engineer?

    You should charge for the cost of our engineer's air tickets, hotel, food, and also their salary 80USD one day per person.


    4. How long is your machine's warranty period?

    All our machine has one year guarantee for electricity parts and two years guarantee for mechanism, starting from finished installation.


    5. How could you do if the parts broken within warranty?

    We would express the free replacement parts during the warranty date


    6. How could you do after one year warranty period?

    We also can-do service for you, but you need pay salary for our technicians 80USD/day for each person.


    7. Does your engineer understand English?

    Our engineers understand a little English. All our engineers have more than five years machine installation experience.


    8. Can you help us find any engineer in our location?

    Of course, we will check and inform you as soon as possible.


    9. How do we solve the machine problem after your engineer leaving?

    Generally speaking, there will be no problem after finishing installation. In case you have any problem, you can contact our sales at any time. Our engineers will take a solution video according your description.
