0.6mpa 400kg H Medicine Spray Granule Powder Coating Dryer Mixing China Manufacturer

    Buy cheap 0.6mpa 400kg H Medicine Spray Granule Powder Coating Dryer Mixing China Manufacturer from wholesalers

    Buy cheap 0.6mpa 400kg H Medicine Spray Granule Powder Coating Dryer Mixing China Manufacturer from wholesalers
    • Buy cheap 0.6mpa 400kg H Medicine Spray Granule Powder Coating Dryer Mixing China Manufacturer from wholesalers
    • Buy cheap 0.6mpa 400kg H Medicine Spray Granule Powder Coating Dryer Mixing China Manufacturer from wholesalers

    0.6mpa 400kg H Medicine Spray Granule Powder Coating Dryer Mixing China Manufacturer

    Ask Lasest Price
    Brand Name : unitedwin
    Model Number : FL-B
    Price : USD
    Supply Ability : 3 sets/ month
    Delivery Time : 3 months
    • Product Details
    • Company Profile

    0.6mpa 400kg H Medicine Spray Granule Powder Coating Dryer Mixing China Manufacturer

    Fluid-Bed Granulator(One-Step Granulator) Fl-B5-1000 Pharmaceutical Powder Granules
    Description:
    The machine is mainly used for the operations of mixing, granulating, drying and coating of granule “Top Spraying”, etc of powder material in pharmaceutical industry, foodstuff industry, chemical industry, etc. Such as granule of tablet, granule for quick resolving drinking, condiment.
    1. The machine is designed and manufactured in accordance with JB20014-2004 < Fluid-bed Granulator In Medicine >
    2. Mixing-granulating-drying in one-step.
    3. Adopting double chamber filtering bags system, removing dust completely.
    4. Adopting multi-fluid nozzle, it guarantees that the formed granule is uniform and the content of powder is very low.
    5. Can choose 2 bar explosion-proof design
    6. Designed, manufactured and laid out by GMP


    Specifications:

     5153060120200300500
    Productive capacity kg/batch5153060120200300500
    Scope of application for liquid(g/cm3
    )
    <1.3
    Material yield rate (%)≥99
    Qualified rate of end products (%)≥85
    Water content of end products (%)Water content of end products (%)
    Granules performance indexConfirm to 2000 edition
    Container volume (L)224510022042067010001500
    Diameter(mm)50055070010001200140016001800
    Power of fan (Kw)35.57.51118.5223045
    Power of supply liquid motor (Kw)0.37
    Pressure of steam (Mpa)0.4-0.6
    Consumption of steam (Kg/h)183560120140180310400
    Pressure of compressed air (Mpa)0.4-0.6
    Consumption of compressed air (m3 /min)0.30.60.90.90.91.11.11.5
    Working temperature(℃)Normal temperature -120℃ could adjust
    Noise (DB)Installed separated with fan ≤75
    Executive standardJB20045-2005
    Overall dimension of machine (L×W×H)Pls refer to installation drawing or customer`s room


    Application:
    0.6mpa 400kg H Medicine Spray Granule Powder Coating Dryer Mixing China Manufacturer0.6mpa 400kg H Medicine Spray Granule Powder Coating Dryer Mixing China Manufacturer
    Company Information:

    0.6mpa 400kg H Medicine Spray Granule Powder Coating Dryer Mixing China Manufacturer
    FAQ:

    1. How long will your engineer reach our factory?
    Within one week after everything ready (machine arrival your factory, non-woven material, power source, air compressor etc. Prepared)

    2. How many days will you finish installing?
    We will finish installation and training within 15 days.

    3. What should we charge for your engineer?
    You should charge for the cost of our engineer's air tickets, hotel, food, and also their salary 80USD one day per person.

    4. How long is your machine's warranty period?
    All our machine has one year guarantee for electricity parts and two years guarantee for mechanism, starting from finished installation.

    5. How could you do if the parts broken within warranty?
    We would express the free replacement parts during the warranty date

    6. How could you do after one year warranty period?
    We also can-do service for you, but you need pay salary for our technicians 80USD/day for each person.

    7. Can you help us find any engineer in our location?
    Of course, we will check and inform you as soon as possible.

    8. Does your engineer understand English?
    Our engineers understand a little English. All our engineers have more than five years machine installation experience.
