Pharmaceutical Round Square Vacuum Dryer China Manufacturer

    Buy cheap Pharmaceutical Round Square Vacuum Dryer China Manufacturer from wholesalers

    Buy cheap Pharmaceutical Round Square Vacuum Dryer China Manufacturer from wholesalers
    • Buy cheap Pharmaceutical Round Square Vacuum Dryer China Manufacturer from wholesalers

    Pharmaceutical Round Square Vacuum Dryer China Manufacturer

    Ask Lasest Price
    Brand Name : UW
    Model Number : YZG/FZG 600
    Price : USD100,000-USD200,000 /set
    Supply Ability : 3 sets/ month
    Delivery Time : 3 months
    • Product Details
    • Company Profile

    Pharmaceutical Round Square Vacuum Dryer China Manufacturer

    YZG/FZG600 Series (Round/Square)Vacuum Dryer


    Description:


    It is well known that vacuum drying is to put raw material under the state of vacuum for heating and drying. If use vacuum to pump air and humidity out, the dry speed will be faster.
    Note: if use condenser, the solvent in raw material can be recovered. If the solvent is water, condenser might be canceled and the investment and every could be saved.

    Specifications:


    specification nameYZG-600YZG-800YZG-1000YZG-1400FZG-15
    inside size of chamber0600x9760800x1274*1000x1572*1400x20541500x1220x1400
    exterior size of chamber1153x810x10201700x1045x13351740x1226x13582386x1657x18002060x1513x1924
    layers of baking shelf44688
    nterval of baking shelf8182102102122
    size of baking disk310x600x45460x640x45460x640x45460x640x45460x640x45
    number of baking disk48123232
    permitted pressure inside ihe pipe of baking shelf (Mpa)W 0.784W 0.784W 0.784W 0.784W 0.784
    temperature inside chamber (*C)30-15030-15030-15030-15030-150
    vacuum level inside chamber with out load (Mpa)-0.1
    h) when vacuim is 30 tar and the hoathg ten-peratire is 110*C, vaporized rate of Eer7.2
    type and powerof vacuum pump without condensate, (kw)2X-15A 2KW2X-30A 3KW2X-30A 3KW2X-70A 5.5kW2X-70A 5.5kW
    type and powerof vacuum pump without condensate, (kw)SZ-0.5 1.5KWSZ-1 2.2KWSZ-1 2.2KWSZ-2 4KWSZ-2 4KW
    weight of drying chamber (kg)25060080014002100

    Application:


    It is suitable for drying heat sensitive raw materials that can decompose or polymerize or deteriorate at high temperature. It is widely used in pharmaceutical, chemical, foodstuff and electronic industries.


    Company Information:


    Pharmaceutical Round Square Vacuum Dryer China Manufacturer

    FAQ:
    1. Are you trading company or manufacturer?
    We are factory.
    2. How long is your delivery time?
    Generally it is 5-10 days if the goods are in stock. Or it is 15-20 days if the goods are not in stock. It is according to quantity.
    3. What should we charge for your engineer?
    You should charge for the cost of our engineer's visa , air tickets, hotel, food ,and also their salary 100USD one day per person.
    4. How long is your machine's warranty period?
    All our machine have one year guarantee, starting from finished installation.
    5. How could we do after one year warranty period?
    We also can do service for you, but you need pay salary for my technician 80USD/day.
    6. How could we do if the parts broken within warranty?
    We would express the free replacement parts during the warranty date.
    7. Does your engineer understand English?
    Our engineer understand a little English. All our engineer have more than five years machine installation experience. In addition, they can use body language to communicate with customer.
    8. Can you help us find any engineer in our location?
    Of course, we will check and inform you as soon as possible.
    9. How do we solve the machine problem after your engineer leaving?
    Generally speaking, there will be no problem after finish installing. In case you have any problem. You can contact our sales at any time. Our engineer will take a solution video according to your description.
