    Geotextile Fabric Extrusion Coating Lamination Line Equipment Multi-function Automatic

    Ask Lasest Price
    Brand Name : UW
    Model Number : UW-M1500
    Price : USD
    Supply Ability : 3 sets/ month
    Delivery Time : 3 months
    • Product Details
    • Company Profile

    Geotextile Fabric Extrusion Coating Lamination Line Equipment Multi-function Automatic

    Extrusion Lamination Coating Machine Geotextile Fabric Multi-function Automatic


    Description:


    UW-M series plastic extrusion laminating line using polypropylene (PP) and low density polyethylene (LDPE) as raw material, after hot melt extrudering film from the barrel, evenly coating at all kinds of substrates such as: woven bag, kraft paper, cloth surface laminating, under the action of laminating device, the substrate bonding strengthof plastic film and substrates ≥ 3N, it can be single or double-sided laminating at one time.


    ▪ Based on glue dot transfer technology, glue is evenly transferred to lining of fabric in the form of dots, and then laminate to shell of fabric.The laminated fabric is resistant to Resistant to dry cleaning, sand washing and washing.


    ▪ The machine use frequency linkage to achieve the whole machine synchronous speed which makes good maneuverability on machine.


    Specifications:


    ModelUW-M1100UW-M1300UW-M1500UW-M1800
    Extrusion die width1100mm1300mm1800mm2000mm
    Coating width500-1000mm700-1250mm800-1500mm900-1700mm
    Max.Coating speed10-150m/min10-150m/min10-150m/min10-150m/min
    Coating thickness0.01-0.03mm0.01-0.03mm0.01-0.03mm0.01-0.03mm
    L/d ratio for screw32:132:132:132:1
    Rewinding roll diameterØ1200mmØ1200mmØ1200mmØ1200mm
    Overall size11500*7000*3200mm12500*8000*3200mm12000*9000*3200mm13000*12000*3200mm
    Total power70kw80kw100kw130kw
    Mirror cool roll diameterØ510mmØ510mmØ510mmØ510mm
    Adopt material

    Application:

    Geotextile Fabric Extrusion Coating Lamination Line Equipment Multi-function AutomaticGeotextile Fabric Extrusion Coating Lamination Line Equipment Multi-function Automatic

    Company information:


    Geotextile Fabric Extrusion Coating Lamination Line Equipment Multi-function Automatic

    FAQ:


    1.Are you trading company or manufacturer?
    We are manufacturer, and also provide the business solution to all the friends.


    2.Do you have quality certificate?
    Yes we have CE, SGS etc.


    3.What's the delivery time?
    Around 20~30days, however, based on order.


    4.Can you help us to buy other goods?
    Sure of that, it is our honor to work for you, and control the goods quality.


    5.what's payment terms ,trade terms you accept ?
    Usually we appreciate T/T 30% deposit , then 70% balance is paid before shipment , we usually offer fob ningbo price. but we alsoaccept other way like L/C , wetern union ,and do CFR&CIF etc.


    6. Is your machine automatic or manual ?
    Automatic.


    7. Does it easy to operate and what can i do if it doesn't work?
    First ,our machine is stable and easy to operate by one man ,what you do is just learn some basic thing like loading the jumboroll paper,start the machine and cutting the paper. And we will sent you manual and video ,we suggest you to come to visit our factory to learn more thing by yourself ,and if there is something goes wrong , you can call us ,video-chat ,email us . And we will give solutions within 36 hrs .Our engineer also can be distributed to overseas as you required.
