    Multi-Function Tandem Hot Melt Extrusion Coating Lamination Line Technology Two Die

    Ask Lasest Price
    Brand Name : UW
    Model Number : SJFM-Z120-2400
    Price : USD
    Supply Ability : 3 sets/ month
    Delivery Time : 3 months
    • Product Details
    • Company Profile

    Multi-Function Tandem Hot Melt Extrusion Coating Lamination Line Technology Two Die

    Two Extruder With Two Die Extrusion Coating Lamination Machine Multi-Function


    Description:


    SJFM series laminating line composites home and abroad laminating line’s similar characteristics, it is designed according to the special requirements of woven bag’s surface laminating features, repeated use in the field with the leading domestic level to improve the advanced unit.


    There are advanced electric meters, pneumatic clutch institutions and mechanisms from the substrate unwinding unit, laminating unit to rewinding unit, which is to achieve a single operating and the group control operation, to improve the degree of automation. Extruder with automatic temperature control, automatic feeding, variable speed control and long lasting Changer, double working position unwinding with adjustable brake to automatically adjust and control on the substrate surface tension. Combined cooling roll laminated using forced water cooling structure, through silicone roll and the pressure roll to laminate. Double working position rewinding unit and adjust edge trimming and waste edge collecting device, the clutch between the different units and the rolls is controled by electric. There are speed governors between different units, the different parts speed can adjustment singlely or at the same time.


    Specifications:


    ItemSJFM-Z95-900SJFM-Z100-1600SJFM-Z120-2400SJFM-Z150-3600
    Die lip width1100mm1550mm2500mm3700mm
    Width of product210-850mm830-1500mm1000-2400mm2000-3500mm
    Max coating speed226m/min236m/min130m/min100m/min
    coat thickness0.008-0.03mm-0.05
    Screw diameter95mm105mm120mm150mm
    Ratio of L/D30:130:130:130:1
    Max. roll diameter of unwinding and winding1100mm1200mm1200mm1200mm
    Overall sizes (L*W*H)

    158000×7500×2300mm

    16800×11000×2800mm

    13300×13000×3200mm

    14800×14000×3400mm

    System installed capacity130kw150kw260kw300kw

    Application:


    Widely used in chemical bags, chemical fertilizer bags and cement bags in chemical metallurgy industry; rice bags and sugar bags in food industry; aquatic products, long material bags and other products.

    Multi-Function Tandem Hot Melt Extrusion Coating Lamination Line Technology Two DieMulti-Function Tandem Hot Melt Extrusion Coating Lamination Line Technology Two Die

    Company information:


    Multi-Function Tandem Hot Melt Extrusion Coating Lamination Line Technology Two Die

    FAQ:


    1.Are you trading company or manufacturer?
    We are manufacturer, and also provide the business solution to all the friends.


    2.Do you have quality certificate?
    Yes we have CE, SGS etc.


    3.What's the delivery time?
    Around 20~30days, however, based on order.


    4.Can you help us to buy other goods?
    Sure of that, it is our honor to work for you, and control the goods quality.


    5.what's payment terms ,trade terms you accept ?
    Usually we appreciate T/T 30% deposit , then 70% balance is paid before shipment , we usually offer fob ningbo price. but we alsoaccept other way like L/C , wetern union ,and do CFR&CIF etc.


    6.does it easy to operate and what can i do if it doesn't work?
    First ,our machine is stable and easy to operate by one man ,what you do is just learn some basic thing like loading the jumboroll paper,start the machine and cutting the paper. And we will sent you manual and video ,we suggest you to come to visit our factory to learn more thing by yourself , and if there is something goes wrong , you can call us ,video-chat ,email us . And we will give solutions within 36 hrs .Our engineer also can be distributed to overseas as you required.
